EPS Wall Panels (Z-lock)
Lightweight, value-led performance for most cool rooms and chillers. Interlocking joints for fast, clean installs.
Business Solutions
Commercial Refrigeration Panels | EPS Coolroom Panels | Cool Room Master
Increase efficiency, reduce costs, and ensure safe product storage with high-quality EPS insulated panels
Commercial Refrigerator Panels
Food-safe EPS insulated wall & roof panels — cut-to-length, hygienic finishes, fast supply. Adelaide-based support from Cool Room Master.
Cut-to-length
Food-grade skins
HACCP-friendly
Adelaide-based support
Our Refrigeration Panel Range
EPS Roof Panels
Efficient roof builds with 1000 mm coverage widths and custom lengths for fewer joints and rapid install.
Channels & Trims
Finish cleanly with aluminium C/L channels, corners and trims sized for your panel thickness.
Questions about sizing? Jump on a quick call — Contact us and we’ll size thickness & trims for your duty cycle.
Why Choose Cool Room Master Panels
Energy-Efficient Builds
Right-sizing thickness reduces compressor load and lifetime running costs.
Hygienic & Food-Safe
Non-porous skins and sealed junctions suit butchers, grocers, bakeries & pharma storage.
Cut-to-Length Supply
Panels cut to spec to minimise waste and speed install across Adelaide, Melbourne & Sydney.
Straightforward Pricing
Transparent product pages with specs and pricing — no surprises at checkout.
How to Choose Panel Thickness
Thickness impacts thermal efficiency and uptime. Use this quick guide then ask us to validate for your room size, ambient heat and door cycles.
| Application | Typical Temp | Recommended Thickness | Notes |
|---|---|---|---|
| Chillers | 0–5 °C | 50–75 mm (EPS) | Great balance for cafés, butchers, grocers. |
| Cool Rooms | 2–8 °C | 50–100 mm (EPS) | Go thicker for hot ambient or high traffic. |
| Freezers | ≤ −18 °C | 100–125 mm (PU/PIR) | Reduces icing risk and compressor runtime. |
Want the deep dive? See our guides: joining panels, fixings and cutting tips.
EPS vs PU/PIR: Which Core Fits Your Application?
| Feature | EPS | PU/PIR |
|---|---|---|
| Thermal performance (per mm) | Very good; excellent value | Higher per mm (often used for freezers) |
| Fire behaviour | Use correct detailing/skins | PIR typically improved performance |
| Cost | Best $/m² | Mid to premium |
| Best for | Chillers & general cool rooms | Freezers & compliance-critical sites |
Cool Room Master vs Bondor — Clear Comparison
Specs can vary by thickness and range, but the table below shows the common choices our customers compare most often.
| Feature | Cool Room Master (our panels) | Bondor (MetecnoPanel® / PIR & EPS ranges) |
|---|---|---|
| Steel skin thickness | 0.45 mm (typical on our wall/roof panels) | Typically up to ~0.6 mm (varies by range) |
| Weight (2.4 m panel) | 15–20 kg — often 1-person install | ~30 kg+ — usually 2-person team |
| Foam density (EPS) | 16 kg/m³ EPS | ~11–12 kg/m³ EPS (PIR density differs) |
| Meets AU standards | ✓ Yes | ✓ Yes (FM/CodeMark on selected lines) |
| Climate ready | ✓ Yes | ✓ Yes |
| Origin | Imported | Australia (Australian-made lines) |
| Steel manufacturer | Baogang Steel | BlueScope® COLORBOND® (on select ranges) |
| Typical pricing (ex-GST) | $40–50 per m² | $70+ per m² (premium AU brands / PIR segment) |
| Best fit | Chillers & general cool rooms, fast turnaround | Freezers & compliance-heavy / architect-led projects |
Notes: Steel skin, density and weight vary by product/thickness. Prices are indicative and depend on thickness, finish, quantity and location. For a firm quote and cut lengths, contact us.
Installation & Accessories
Best Practices
- Level substrate and vapour barriers where required.
- Engage Z-lock joints fully; seal penetrations immediately.
- Use food-safe silicone/PU sealant at junctions.
- Commission baseline temps & energy for ongoing checks.
Handy reads: join panels, screws & fixings.
Complete Your Build
FAQ: Commercial Refrigeration Panels
Do you deliver across Australia?
Yes. We supply cut-to-length panels and arrange delivery nationwide; installs available in major metros. Contact us.
Can I upgrade an existing cool room?
Often yes. We can replace damaged sections, add hygienic trims, and improve door seals to boost performance.
What thickness should I choose?
Chillers commonly 50–75 mm EPS; freezers 100–125 mm PU/PIR. We’ll confirm after a quick duty/ambient assessment.
Do you provide trims & channels?
Yes — see parts & accessories.
Ready to spec your refrigeration panels?
Tell us your room size, target temperature and location. We’ll recommend core, thickness and trims — and quote delivery.
